Платы OpenMV¶

Камеры OpenMV и платы Arduino, работающие под управлением прошивки OpenMV. На каждой странице приведены полная распиновка, отображение периферии, поддерживаемые драйверы и примечания по конкретной плате.

Камеры OpenMV¶

OpenMV N6 New

STM32N6 with built-in NPU — STMicro's first AI-accelerated MCU.

OpenMV AE3 New

Alif Ensemble E3 — fusion-class Cortex-M55 with Ethos-U55 NPU.

OpenMV RT1062

NXP i.MX RT1062 Cortex-M7 at 600 MHz with 32 MB external SDRAM.

OpenMV Pure Thermal

Pure Thermal

Dual color and thermal imaging plus DVI/HDMI output and a built-in touch LCD, STM32H7 host.

OpenMV H7 Plus

STM32H743 with 32 MB external SDRAM and a 5MP OV5640 sensor.

OpenMV H7

STM32H743 Cortex-M7 with a removable image sensor module.

OpenMV M7 Legacy

STM32F765 Cortex-M7 — successor to the M4 with more memory and speed.

OpenMV M4 Legacy

STM32F427 Cortex-M4 — the first OpenMV Cam.

Платы Arduino¶

Arduino Nicla Vision

Arduino Nicla Vision

Compact 23 × 23 mm STM32H747 board with on-board sensor.

Arduino Portenta

Arduino Portenta

STM32H747 with 8 MB SDRAM and Vision Shield support.

Arduino Giga

STM32H747 with 8 MB SDRAM, Vision and Display Shield support.

Arduino Nano RP2040 Connect

Arduino Nano RP2040 Connect Unsupported

RP2040 Cortex-M0+ with U-blox NINA Wi-Fi/BLE.

Arduino Nano 33 BLE Sense

Arduino Nano 33 BLE Sense Unsupported

Nordic nRF52840 sensor board — no on-board image sensor.
